Short info
GTR-01 is a hardware system generating true random numbers. The innovative multiplatform design, convenient USB interface, the high data rate of up to 2.2 Mb/s and the compact size of GTR-01, make it the right choice for many applications related to cryptography and network security, scientific research, computer simulations, modeling, lotteries, gambling, applied mathematics and statistics, etc. In many of the above areas, it is important to use a hardware source of random numbers based on a physical phenomenon, unlike the computer-generated pseudorandom numbers using a known and predictable numerical algorithm.
Basic features
Quantum phenomenon as a source of entropy
GTR-01 uses avalanche noise in the reverse-biased p-n junction as a primary entropy source.
Two completely independent analog channels with software XOR function
Two independent entropy sources and built-in XOR-ing for maximum output quality.
12-bit precise calibration with EEPROM values storage
Built-in precise calibration procedure ensuring 12-bit accuracy for every of the two entropy channels. Calibration coefficients are stored in the electrically independent EEPROM memory.
High data output rate through a standard USB interface
GTR-01 has a max output data rate of 2.2 Mb/s. The convenience of the USB interface makes the connection with the computer easy and secure.
Multiplatform design including Windows, Linux, Mac OS and Android
GTR-01 quantum random generator is designed to be used on different software platforms and operating systems. Software API ensures easy connection in any application environment.
Programming API including GUI application, examples and low-level drivers
StudioGTR™ .NET GUI software application for monitoring, testing, and calibrating of the GTR-01 quantum generator. Intuitive interface and easy operation. Low-level code examples are written in C#.
Statistically validated output data stream quality
The randomness and unpredictability of the output binary data stream are statistically tested and validated using NIST STS, TestU01 and Diehard.
Compact and robust design
The hardware is built into a compact and robust aluminum shielded enclosure.
On the library page, you can find more articles about our products, projects we participate and scientific research we do.
Go to libraryWhat it is used for?
Cryptography and security
GTR-01 generates true random numbers. It is a hardware system based on a physical quantum process used as a source of entropy. Thus, the inherent unpredictability of the output data stream ensures a high degree of security in the generation of cryptographic keys or PINs used in network communications. The binary data sequences are reliable and of the highest quality. Unlike the so-called pseudorandom numbers obtained by a strict mathematical algorithm, cryptographic keys and PINs generated by GTR-01 cannot be predicted by an outside malicious third party and have the highest degree of security.
Lotteries and gambling
GTR-01 is a reliable and secure random number generator and can be used in the gambling industry, bingo games, casinos, TV shows, online games and lottery. Also, it can be embedded as a hardware source of entropy in slot machines and other gambling equipment. GTR-01 is the best choice for generating the lucky
numbers used by the individual players to participate in the lottery games.
Scientific research and computer simulations
The use of random numbers in modern research is immense! Without a secure source of randomness, it is not possible to even imagine how authentic results can be achieved in any field of science. From the fundamental physics, nuclear and particle interactions, space research, computer modeling and Monte Carlo simulations, statistical analysis, mathematical algorithms, engineering and industry, computer games, virtual reality and special effects in cinema, to chemical and biological modeling, testing of new drugs and vaccines used in medicine, social and political sciences, modeling of populations and human society, research in sociology, psychology, brain activity and human behavior, and even studies in the occultism, divination, paranormal phenomena and much more. Random numbers are everywhere! The use of a secure, hardware random number generator in all these fields of science is vital. GTR-01 is one of the best quantum generators on the market and is the ultimate choice as a source of randomness used in scientific research.
Tech info
Technical specifications
| Specifications | |
|---|---|
| Entropy source | Avalanche noise, reverse-biased p-n junction |
| Number of independent channels | 2 |
| XOR | Yes |
| Max bit rate | 2.2 Mb/s |
| Operating temperature range | 0 ÷ 50 °C |
| Platform | Windows, Linux, Mac OS, Android |
| Dimensions | 74 x 41 x 15 mm |
| Weight | 50 g |
System requirements
| Requirements | |
|---|---|
| Operating system | Windows XP*, Vista, 7, 8, 8.1, 10; 32-bit / 64-bit |
| CPU | 1 GHz or better; 32-bit / 64-bit |
| RAM | 1 GB or more |
| Screen resolution | 1024 x 768 or higher |
| Hard disk free space | 50 MB or more |
| USB | 2.0, 3.0 or 3.1; single port |
| Adobe Acrobat Reader | Version 9.0 or higher |
*Windows XP requires .NET Framework 2.0 or higher to be installed.
In the set
| Content | |
|---|---|
| GTR-01 hardware unit | 1 pc. |
| USB cable | 1 pc. |
Downloads
Here you can download the latest version of the StudioGTR software and GTR-01 quantum generator's drivers. StudioGTR is an easy maintenance application and virtually does not need to be installed at all. Just unpack the studiogtr.zip file somewhere on your system, for example, in the C:\Program Files\StudioGTR and put a shortcut to the application’s .exe file on your Desktop or Start menu. More information about the software and drivers installation you can find in the User manual.
NOTE: Do not change the structure and content of the unpacked zip archive.
NOTE: The driver package contains two folders. The first one is labeled (XP, Vista) and is for older versions of Windows XP and Vista. The other one, labeled (7, 8, 8.1, 10), contains drivers for newer versions of Windows 7, 8, 8.1, and Windows 10. Additionally, on Windows XP, the Framework .NET 2.0 or later should be installed to get StudioGTR working.
NOTE: The StudioGTR zip archive contains an executable file. Some antivirus software may restrict it from the download. Please, check the settings of your antivirus program.
